Ball Valve
Ball Valves - BAV
Resilient Seat - Ball Valves
Metal Seat - Ball Valves
Ball valves - Designing Standards :
EN 1983 - Industrial valves — Steel ball valves
API 6D Specification for Pipeline Valves
API 608 Metal ball valves.
Flanged, Threaded and Welding Ends Fourth Edition
ASME B16.34 Valves—Flanged, Threaded, and Welding End
MSS SP-72 Ball Valves with Flanged or Butt-Welding Ends for General Service
ISO 17292 Metal Ball Valves for Petroleum,
Petrochemical and Allied Industries
ISO 5211 Part-turn Valve Actuator Attachments
NACE MR0175 Metals for Sulfide Stress Cracking and Stress Corrosion Cracking Resistance in Sour Oilfield Environments
BS 6364 Valves for Cryogenic service
EN 1626:2008 Cryogenic vessels — Valves for cryogenic service
Ball valves - End Connection Standards :
EN 1092-1: 2007+A1:2013 Flanges and their joints — Circular flanges for pipes, valves, fittings and accessories,
PN designated — Part 1: Steel flanges
EN 1515-4 : 2009 Flanges and their joints — Bolting
Part 4 : Selection of bolting for equipment subject to
the Pressure Equipment Directive 97/23/EC
ASME B16.5 Pipe Flanges and Flanged Fittings
B16.47 Large Diameter Steel Flanges
B16.11 Forged Fittings, Socket-Welding and Threaded
API 605 Large Diameter Carbon Steel Flanges
MSS SP-44 Steel Pipe Flanges
EN 12627 Industrial Valves, Butt Welding Ends Steel Valves
EN 12760 Valves-Socket welding ends for steel valves
• Download Ball Valves Catalog :
Ball Valves Floating & Trunnion mounted resilient
& Metal seated. / Cryogenic Ball Valves
Ball valves / Resilient Seat Applications :
Resilient-seated ball valves have good sealing performances
and a variety of choices for the materials depending on the working conditions.
Resilient-seated Ball valves are widely used for pure medium,
such as water, LNG, coal gas, natural gas, oil, nitric acid.
Resilient Seat Parameters :
Nominal diameter : 1/2" ~ 48" (DN15 ~ DN1200)
Pressure class : Class150 ~ Class2500 (PN16 ~ PN420)
Working Temperature : -196˚C ~ 260˚C
Structure : floating ball / trunnion mountedBody
Type : two-piece / three-pieceMaterial forming
process : cast / forged
Drive type : manual, worm gear, electric, pneumatic, hydraulic
Ball valves / Metal Seat
Applications :
Metal seated ball valves are suitable for cryogenic, high temperature, high pressure, abrasive and corrosive working conditions. It is an ideal equipment to shut off some special medium, such as the solid and gas mixed medium, solid and liquid mixed medium, high-viscosity medium, high-fiber medium, high temperature steam. It is widely used in the coal chemical, petrochemical, papermaking, poly-silicon industries and power stations.
Metal Seat - Parameters
Nominal diameter :
1/2" ~ 48" (DN15 ~ DN1200)
Pressure class : Class150 ~ Class4500 (PN16~PN760)
Working temperature : -196˚C ~ 650˚C
Structure : floating ball / trunnion mounted
Body type : two-piece / three-piece
Material forming process : cast / forged
Drive type : manual, worm gear, electric, pneumatic, hydraulic
Face to Face Standards :
ASME B16.10 Face-to-Face and End-to-End Dimensions of Valves
ISO 5752 Metal valves for use in flanged pipe systems
Face-to-face and center-to-face dimensions
BS 558 Industrial Valves Face To Face & Center To Face Dimensions
Testing and Inspection Standards :
API 598 Valve Inspection and Testing
API 6D Specification for Pipeline Valve
API 6FA Specification Fire Test For Valve / API 607 for Soft Seats
BS 12569 Industrial valves
- Valves for chemical and petrochemical process industry
- Requirements and tests MSS SP-55 Quality Standard
for Steel Castings for Valves,
Flanges, Fittings, and Other Piping Components
– Visual Method for Evaluation of Surface Irregularities EN 764-5:2002 Pressure Equipment
— Part 5 : Compliance and Inspection Documentation of Materials
EN 12266-1:2012 Industrial valves — Testing of metallic valves
EN 12569:1999 Industrial valves.
Valves for chemical and petrochemical process industry. Requirements and tests.
Marking of Ball Valves
EN 19:2002 Industrial valves — Marking of metallic valves
